Megger MIT300 250/500V Insulation and Continuity Tester

Megger MIT300 250/500V Insulation and Continuity Tester

Suitable for use in domestic, commercial and industrial applications, the MIT300 is capable of testing insulation at 500V and 250V DC and also includes a built-in continuity testing function with integrated buzzer.

Megger's MIT300 is uniquely designed, with a built-in protective cover that fits over the screen and dials to protect it during transportation. It's also weatherproof to IP54, allowing limited use outdoors

Features:

• Extremely easy to use
• Tough rubber armoured case
• Self-contained protective cover
• Live circuit warning„Weatherproof to IP54
• Intelligent Safety System for protection.
• Result storage and downloading
• Download software included
• USB interface
• Compatible with CertSuite.app
• Beeps and flashes V on the display
• Nominal Test Voltage: 500V, 250V (DC)
• Short Circuit Current: 205mA + 10mA -5mA
• Zero Offset Adjust: 0 - 9?
• Open Circuit Voltage: 1.5V ± 0.5V
• Measuring Range: 999M
• Test Current on Load: 1mA at min. pass values of insulation (as specified in BS7671, HD 384 and IEC 364)

Included Items:

• Megger MIT300 Insulation and Continuity Tester
• Test lead set and crocodile clips
