Megger MIT320 250/500/1000V Insulation and Continuity Tester

Megger MIT320 250/500/1000V Insulation and Continuity Tester

The Megger MIT320 is the second-highest specification model available in Megger's MIT300 series and is the upgraded version of the MIT300, MIT310 and MIT310A.

Megger's MIT320 can perform insulation tests with test voltages of 250, 500 and 1000V with maximum testing range of up to 999M. Testing procedures can be activated directly from the tester, or alternatively you can use the switched probe supplied with the MIT320 to activate the tests remotely. For added convenience, continuity testing will automatically activate when connected to the circuit.

Features:

• Extremely easy to use
• Tough rubber armoured case
• Self-contained protective cover
• Live circuit warning„Weatherproof to IP54
• Intelligent Safety System for protection.
• Result storage and downloading
• Download software included
• USB interface
• Compatible with CertSuite.app
• Nominal Test Voltage: 1000V, 500V, 250V (DC)
• Measuring Range: 999M
• Open Circuit Voltage: 5V ± 1V
• Short Circuit Current: 205mA + 10mA -5mA
• Measuring Range: 0-2/20/200/2k
• Zero Offset Adjust: 0 - 9?
• Continuity Buzzer: 1? to 20?
• Measuring Range: 10? to 1M?
• Open Circuit Voltage: 5V
• >25V AC or DC is applied display will operate as a voltmeter

Included Items:

• Megger MIT320 Insulation and Continuity Tester
• Test lead set and crocodile clips
• SP4F Switch probe
